    In order to install a Custom recovery like TWRP or CWM or a custom ROM like: CyanogenMod, Resurrection Remix etc., on your Le Eco Le 1s – x507 Android phone the bootloader must be unlocked. Here is a very simple Step By Step Le Eco Le 1s Bootloader Unlock Guide.

    DISCLAIMER:
    Unlocking the bootloader on your Android may VOID your warranty and may delete all your data. You are solely responsible for anything that happens to your device because you are the only person doing changes to your phone and I cannot be held responsible for the mistakes done by you in anyway.

    Before proceeding further you may consider backup your all data. Here is a Step by step guide to take full backup of your phone data.

    Le Eco Le 1s Bootloader Unlock Guide

    Required Files for this Le Eco Le 1s Bootloader Unlock Guide:

    Step By Step Le Eco Le 1s Bootloader Unlock Guide:

    Unlocking Bootloader Method #1:

    If you don’t know the key combination to press enter into bootloader mode in Le Eco Le 1s or if you are a newbie to Android Customization then this process is strongly recommended to Unlock Bootloader on your Android:

    1. Download and install the ADB and Fastboot binaries using the above installer download link for Windows.
    2. Enable USB Debugging under Developer Options on Le 1s. Here is How to Enable Developer Options and How to Enable USB Debugging under Developer Options.
    3. Open the command console on your PC. To open a command window in the current directory in Windows, press shift + Right Click anywhere on Windows explorer, or some folder. Then on the menu opened, just press the “w” key on the keyboard or select “Open command window here” to open a command window.
    4. Now connect your Android to the PC using a USB cable.
    5. Enter the following command on the command window opened:
      adb reboot bootloader

      to put your Android into bootloader mode where you can flash/install the TWRP recovery.
      If your Android device asks permission such as “Allow USB debugging” then just tap on OK to proceed.

    6. Now when your Android is on the bootloader mode just execute the following command on the console:
      fastboot oem unlock

      This will Unlock the bootloader and delete all user data present on the phone. Here is a Step by step guide to take full backup of your phone data

    7. After executing the above command, confirm Bootloader Unlock on Le 1s by pressing Volume Up button on your Le Eco Le 1s.

    Unlocking Bootloader Method #2:

    If you know how to enter into bootloader mode on your Le Eco Le 1s by pressing key combinations then follow the below steps to Unlock Bootloader on your Android:

    1. Download and install the ADB and Fastboot binaries using the above installer download link for Windows.
    2. Enter into fastboot or bootloader mode by pressing your device specific key combinations on Le 1s, open a command console on your PC and then execute the following command on the console:
      fastboot oem unlock

      This will Unlock the bootloader and delete all user data present on the phone. Here is a Step by step guide to take full backup of your phone data

    3. After executing the above command, confirm Bootloader Unlock on Le 1s by pressing Volume Up button on your Le Eco Le 1s.

    Congratulation!!! You have now successfully unlocked the Bootloader of you Android and welcome to the developer world where you are yet to experience many more things on Android customization. The very NEXT STEP you may want is to install TWRP recovery on your Android or want to ROOT it.
    Below are some guides:
    How to Install TWRP recovery on Le 1s

    Lineage OS ROM | Linux How to Guides
