Download LineageOS 16 for Moto G5 Plus

Viewing 4 posts - 1 through 4 (of 4 total)
  • Author
    Posts
  • #55342
    Siba
    Keymaster

    You can now download and install LineageOS 16 for Moto G5 Plus. Here is how to install LineageOS 16 on Moto G5 Plus, with a step-by-step guide. This Moto G5 Plus LineageOS 16 build is brought to you by developer sandy108.

    Follow the links to get other LineageOS 16 Download and Android Pie ROM builds.

    DONATION TO DEVELOPER(S)/PROJECT:

    If you like this ROM then do consider for a contribution to sandy108 and LineageOS project:
    Donate to LineageOS project
    – no donation link found for sandy108



    Download LineageOS 16 for Moto G5 Plus


    [su_note note_color=”#F9D9D9″ text_color=”#AA4343″ radius=”3″ class=”” id=””]DISCLAIMER:
    THIS IS AN INITIAL BUILD OF LineageOS 16 FOR Moto G5 Plus, WHICH MAY HAVE BUGS.
    MAKE SURE TO BACKUP ALL DATA OF YOUR PHONE.
    FLASH AT YOUR OWN RISK.[/su_note]

    [su_note note_color=”#FBF4DD” text_color=”#A38C68″ radius=”3″ class=”” id=””]Installing a custom ROM may require an unlock bootloader on Moto G5 Plus, which may VOID your warranty and may delete all your data. Before proceeding further you may consider backup all data on the phone.
    You are the only person doing changes to your phone; neither the developer nor I can be held responsible for the mistakes done by you.[/su_note]

    Status of the Moto G5 Plus LineageOS 16 ROM:

    WHAT’S WORKING:
    – Almost Everything



    KNOWN ISSUES:
    – Encryption

    REQUIRED GUIDES AND DOWNLOADS TO INSTALL LineageOS 16 ON Moto G5 Plus:

    HOW TO DOWNLOAD AND INSTALL LineageOS 16 ON Moto G5 Plus – Android 9 Pie CUSTOM ROM:

    [su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]
    Following are the two sub-sections of this Moto G5 Plus LineageOS 16 guide:

    1. First time installation of LineageOS 16 on Moto G5 Plus
    2. Upgrading LineageOS 16 on Moto G5 Plus from a previous build of LineageOS 16 ROM

    [/su_note]

    Flashing LineageOS 16 on Moto G5 Plus for the first time:

    [su_note note_color=”#FBF4DD” text_color=”#A38C68″ radius=”3″ class=”” id=””]
    Points to NOTE:

    • Try to avoid restoring apps backup using Titanium Backup. It may break things up.
    • Don’t restore system data using Titanium Backup! It will definitely break the current installation.
    • It is also discouraged to Restoring Apps + Data using Titanium Backup.

    [/su_note]



    1. Download and Copy the LineageOS 16 Gapps and the Moto G5 Plus LineageOS 16 Android Pie ROM ZIP file to your phone.
    2. Boot into the TWRP custom Recovery to install this LineageOS 16 on Moto G5 Plus.
      [su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]- Make sure to have a Custom recovery like a TWRP recovery or any other custom recovery.
      – If not then download the TWRP recovery from Downloads link and follow the Custom Recovery Installation Guide (it’s a generic guide which will work for TWRP as well as any other recovery)
      [/su_note]
    3. Wipe the data partition (or do a factory reset), Cache partition, Dalvik Cache or ART cache and Format the System partition.
      [su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]- Here is a guide explaining how to wipe using TWRP recovery.[/su_note]
      [su_note note_color=”#FBF4DD” text_color=”#A38C68″ radius=”3″ class=”” id=””]This will delete all your data on your phone. You may consider complete backup of your phone data or take a NANDROID backup of the current ROM
      How to backup all data on your Android Device
      how to take NANDROID backup using TWRP recovery[/su_note]
    4. Install the Moto G5 Plus LineageOS 16 ROM file that you have copied into the phone.
      [su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]- Here is a post explaining how to install LineageOS[/su_note]
    5. Then install the Android Pie MindTheGapps for LineageOS 16 package.
      [su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]- Here is a post explaining how to install GApps using TWRP recovery.[/su_note]
    6. Reboot and Enjoy the Android 9 Pie LineageOS 16 on Moto G5 Plus.

    Upgrading from earlier version of LineageOS 16 on Moto G5 Plus (potter):

    1. Copy the latest ROM zip file of LineageOS 16 for Moto G5 Plus, LineageOS 16 GApps and/or Magisk ROOT package to the phone
    2. Boot into Recovery to flash the updated LineageOS 16 on Moto G5 Plus
    3. Format or wipe the system partition from the custom recovery menu.
    4. Install the LineageOS 16 for Moto G5 Plus.
      [su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]- Here is a post explaining how to install LineageOS[/su_note]
    5. Reboot and see you have the GApps and ROOT access or NOT.
      [su_note note_color=”#D8F1C6″ text_color=”#769958″ radius=”3″ class=”” id=””]- Gapps is built in such a way that it will sustain across ROM updates.[/su_note]
    6. If you don’t have GApps after upgrading the LineageOS 16 on Moto G5 Plus, then flash the GApps.
      [su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]- Here is a post explaining how to flash GApps using TWRP recovery.[/su_note]
    7. If you don’t have ROOT after upgrading the LineageOS 16 on Moto G5 Plus, then flash the SuperSU or Magisk or the Lineage SU binary.
      [su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]- Here is a post explaining How to Enable ROOT on LineageOS 16 ROM[/su_note]
    8. Once everything is done, reboot and Enjoy the LineageOS 16 on Moto G5 Plus.

    [su_note note_color=”#D8F1C6″ text_color=”#769958″ radius=”3″ class=”” id=””]Complete the initial setup and enjoy Android 9 Pie with LineageOS 16 on Moto G5 Plus.[/su_note]

    Add-on links after installing LineageOS 16 on Moto G5 Plus

    LineageOS 16 ROOT
    GCam 6.1 for Moto G5 Plus

    [su_note note_color=”#D7E3F4″ text_color=”#728095″ radius=”3″ class=”” id=””]If there is no ROOT access for some reason even after installing the LineageOS SU binary, then you can try SuperSU rooting guide to enable ROOT access.[/su_note]

    Stay tuned or Subscribe to the Moto G5 Plus (potter) LineageOS forum For other Android Pie, Android Oreo ROMs, Nougat ROMs, or other ROMs and all other device specific topics.
    #57888
    Linux User
    Participant

    hice la instalacion como indica y los servicios de google no funcionan (por las dudas instale las dos opciones de apps de google y tampoco, haciendo los wipe correspondientes entre una y otra), lo poco que pude usar funciona muy fluido. tuve que volver a la rom stock de motorola. moto g 5 + xt 1681

    ojala puedan solucionar este incoveniente, realmente funciona el resto de la rom muy bien!

    English Translation:
    I did the installation as indicated but the google services do not work (just install the two options of google apps and not, making the corresponding wipe between them), the little I could use because of that otherwise it works very smoothly.

    I had to go back to the motorola stock rom. moto g5 + xt 1681
    I hope you can solve this inconvenience; otherwise it really works very well with the rest of the rom!

    #64399
    Linux User
    Participant

    Hello friends, my finger scanner is not working.

    I went from having stock rom to LineageOs 16, everything seems to be working fine.

    the only problem is with the finger scanner.

    Can someone please help me get the scanner working?

    Moto g5 Plus

    #78751
    Linux User
    Participant

    Congratulations for this mod. I’ll leave some comments that may help people here.

    I tried to install this mod in many different ways, and got many different problems.

    1) Tried with TWPR twrp-3.2.3-1-potter.img and installed LOS 16 + opengapps 9.0

    Used: lineage-16.0-20181007-UNOFFICIAL-potter / lineage-16.0-20181107-UNOFFICIAL-potter / open_gapps-arm64-9.0-nano-20190409

    I got some encryption problem… it requested a password, I put “default_password”, it said password was fine, but something else was broken. When I tried to wipe partition on TWPR I got some errors. So, I downgraded TWPR

    2) Tried with twrp-3.2.1-1-potter_crypto.img and installed LOS 16 + opengapps 9.0

    Used: MindTheGapps-9.0.0-arm64-20180809_192137 / MindTheGapps-9.0.0-Unofficial-arm64-20180818 / MindTheGapps-9.0.0-arm64-20190216_211116 / open_gapps-arm64-9.0-nano-20190409

    Now I passed encryption part. After it requested my wifi connection, it connected but got stuck on “checking for updates…” forever. I rebooted many times, wiped out everything and tried again. No success.

    I heard it might be a problem with opengapps, so I tried MindTheGapps too… tried too many versions, but no progress. I reverted TWPR to the newest version again, but also no progress.

    3) Finally, tried with TWPR twrp-3.2.3-1-potter.img and installed LOS 15.1 + open_gapps 8.1

    This was the only way I got it working on potter Moto G5 Plus: installing  lineage-15.1-20190408-UNOFFICIAL-potter with open_gapps-arm64-8.1-nano-20190409.

    I guess this was the post: https://cyanogenmods.org/forums/topic/lineageos-15-1-for-moto-g5-plus-android-oreo-8-1

    Using this tutorial, I managed to pass the wifi situation, but noticed there’s no tray bar anymore. Since there’s no “back” button, or anything else, I thought it was another bug on the system!

    4) Configuration of biometric reader to perform “back” and other operations

    OPTION 1: I needed to find “Settings” on top screen, and go to “Moto Actions”, to add “gestures on biometric sensor”. I defined a single click as “back”, double click as “home” and long click as “recent”.

    OPTION 2: Go to “Settings” on top screen, then “System” -> “Buttons” -> “Enable screen navigation bar”. This is more “classic” (three buttons on screen), but also consumes part of the screen.

    —-

    This was the necessary steps to make it work on my Moto G5 Plus. Hope this helps others, and I hope I manage to go to LOS 16 soon enough :)
